Van Damme Pro OFC Custom Audiophile Gold Rca Phono Interconnector Cable Leads
By Energize Audio!
Featuring our own high quality gold plate RCA'S
All Colours now Available!
Custom Labels printed on request.
· Van Damme Pro Grade Classic XKE Instrument Cable is a relatively low capacitance unbalanced audio cable. Its tight construction and dual screens of conductive thermoplastic and close lapped copper ensure noise free handling and excellent noise rejection.
· Van Damme cables has been designed, engineered and refined for over two decades as a result of technological advances and customer driven requirements. The result is a place among the best stages, studios and screens across the world.
· Bespoke cables are professionally made and tested.
· This sale is for a pair of cables, (2 cables for left and right channels).
︎Custom Hand Built.
︎Soldered with Kirstall / Crystal 505
︎Super Signal Transfer & Performance Without Signal Loss
︎Terminated With High Quality Gold Plated Rcas.
︎Made To High Standards And Fully Tested Before Dispatching.
This Listing Is For A Pair Of Audio Cables Various Lengths (2x Rca's To 2x Rca's)
classic instrument series Mechanical specification Conductor Material Bare silver plated ultra pure oxygen free copper wire Stranding 3 x 0.20mm Material Bare ultra pure oxygen free copper wire Stranding 4 x 0.20mm Insulation Material Foamed Polyethylene Diameter 1.60mm ±0.10 Screen 1 Type 0.40mm conductive thermoplastic Screen 2 Type 80 x 0.10mm close lapped oxygen free copper wire Jacket Material Flexible PVC/Neoprene composite Average thickness 1.70mm Overall diameter 6.00mm ±0.15 Physical properties unaged Jacket (at 60ºC) Tensile strength >8N/mm2 Elongation >250% Heat shock test 120 ºC x 1 hour – no cracks Test voltage 1000 Vdc x 1 minute OK Electrical characteristics Resistance Conductor Ohm/Km 47 Insulation M Ohm/Km >5000 Capacitance Core to shield pF/m <90
